Mercury-OCT™ High Speed Spectrometers
High throughput - f/2 Optics - Fast Scanning Speed - Broad Spectral Range Request a QuoteDownload Instrument PDF
Optical Coherence Tomography (OCT) Spectrometers
Similar Searches: Raman Probes, Raman Lasers, Raman Microscopes, Portable Raman Analyzers, Raman Libraries
Mercury-OCT-500 and Mercury-OCT 800 offer multiple wavelength ranges and imaging depths. Contact us for more information.
Optical Coherence Tomography (OCT) is a non-invasive imaging technique that captures high-resolution, cross-sectional images of biological tissues. OCT is widely explored in research and medical diagnostics for its potential to revolutionize the detection and monitoring of diseases such as glaucoma, macular degeneration, and cardiovascular conditions.
The Mercury-OCT Spectrometer Engine offers unprecedented performance and affordability for OCT applications.
- Fast Scanning Speed: Rapid data acquisition for real-time imaging, critical for dynamic processes.
- Broad Spectral Range: Enhanced imaging depth and contrast for various tissue types.
- Affordability: StellarNet is your low cost leader in spectroscopy solutions and brings the new Mercury-OCT Engine to market with leading price points.
- Multiple Mercury Configurations: Mercury-OCT-500 and Mercury-OCT 800 offer multiple wavelength ranges and imaging depths.
Mercury-OCT-500 Spectrometers offers high speed 130kHz scanning over the VIS spectral range (515-660nm) with 1mm imaging depth capability using 2048 high sensitivity CMOS detector.
Mercury-OCT-800 Spectrometer offer high speed 130kHz scanning over the NIR spectral range (790-940nm) with 2mm imaging depth capability using 2048 high sensitivity CMOS detector.
Model Ranges and Resolutions
| Mercury-OCT Spectrometer | Wavelength Range (nm) | 10x Optical Gain/High Speed | Imaging Depth (mm) | Resolution (nm) |
|---|---|---|---|---|
| Mercury-OCT-500 | 515-660 | Yes | 1 | 0.1 |
| Mercury-OCT-800 | 790-940 | Yes | 2 | 0.1 |
Technical Specifications
| Optical Parameters | |
| Spectral Range 500; 800 | 515-660nm; 790-940nm |
| Optical Resolution 500; 800: | 0.1nm; 0.1nm |
| Imaging Depth 500; 800 | 1mm, 2mm |
| Spectrograph Aperture: | f/2 |
| Gratings: | Transmissive High Throughput |
| Optical Gain: | >10x signal enhancement |
| Stray Light: | <0.05% |
| Optical Input: | SMA-905 |
| Detector & Electronics | |
| Detector Type: | 2048 pixels CCD/CMOS/PDA 14um x 200um |
| Detector Lens: | Advanced cylindrical lens assembly |
| Scan Speeds: | 130 kHz |
| Signal to Noise: | >1000:1 |
| Physical | |
| Dimensions: | 6 x 17 x 15.5 cm |
| Weight: | 2.5 kg |
| Software & Interface | |
| Operating System: | Windows, Linux |
| Interface: | USB-2 (Wifi & Webserver Options) |
| Software: | StellarPro, LabView, Spectroscopy Pro-tools, Delphi, C, C# |
